bisami lah ra7mani ra7im

18/12/2006 23:37 par aluminuom123

ali

23/10/2006 00:24 par aluminuom123

        ali

aluminoum 7000

19/08/2006 01:16 par aluminuom123

A sliding system with 70 mm section in the frames, 24 mm section in the leaves and 8 mm European rail. As the above, it has three-rail frames, plinth, and lateral frame with in-built guide. Also, it fits 2300 series leaves, which makes it still more versatile. As with the 2300, accessories come conveniently packed in bags to facilitate use and reduce stocks		SYSTEM: 2 to 6-Leaves Slider SECTION: 2-rails Frame: 70 mm. 3-rails Frame: 102 mm. Leaf: 24 mm. OVERALL WIDTH: 1.4 mm. THERMAL BREAK: No SILL HEIGHT: 18 mm. GLASS GAP: Maximum 18 mm. APPROVALS: A: 3 / E: 5A / V: C2 FINISHING: Anodized and lacquered.
Homologación
TECHNICAL DATA
CODE FIGURE DESCRIPTION WEIGHT (kg/m) TOTAL PERIMETER (cm) FACES Jx mm4 Jy mm4 E-0036   WINDOW OVERLAP 0.174 10.3 3 190 11096 E-0245   PRE-FRAME 120 MM 0.773 38.1   9654 394698 E-0380   MONOBLOCK BOX OVERLAP 0.202 12 2 2364 7878 01003   ROLLER SHUTTER GUIDE – 120 MM SLAT 0.947 53.2 1 54836 443832 01004   ROLLER SHUTTER GUIDE – 120 MM SLAT 0.947 53.2 1 63809 482212 01036   DOUBLE ROLLER SHUTTER GUIDE 1.005 60.2 2 33385 391321 01071   MONOBLOCK ADJUSTABLE CORNER PROFILE - SOCKET 1.188 64.3 1 102040 861655 1073   TOP OVERLAP 0.200 12 1 730 9160 3207   ROLLER SHUTTER GUIDE - 120 mm SLAT WITH SCOOPER 1.057 61.5 1 91662 792056 3215   ROLLER SHUTTER GUIDE - 120 mm SLAT WITH SCOOPER 2.133 72.4 2 1180370 2258364 3216   MONOBLOCK ADJUSTABLE CORNER PROFILE - PLUG 2.090 70.1 2 1095195 2030794 3416   CORNER PROFILE 1.085 53.5 3 303225 303225 4657   LOWER FRAME EXTENSION 0.344 19.7 1 176 94225 6079   ADJUSTABLE CORNER PROFILE - SOCKET 0.683 33.4 2 70442 173051 6080   ADJUSTABLE CORNER PROFILE - PLUG 0.792 33.3 2 78785 253868 10916   CURVED OVERLAP 0.288 16.5 1 2805 16995 72014   PRE-FRAME 50 MM – THICKNESS 1.25 MM 0.424 25   9242 38778 80012   REINFORCEMENT PROFILE 0.852 33.6 3 48491 59657 80013   REINFORCEMENT PROFILE CLAMP 0.132 7.3   506 1506 94103   WINDOW CROSS-PIECE – 11 CHAMBER 0.747 41.5 2 50631 56547 94301   BEAD 18 MM 0.225 16.4 2 4968 6272 94302   BEAD 24 MM 0.205 15 2 3403 4989 94303   BEAD 28 MM 0.198 14.4 2 2158 4913 94407   OVERLAP 0.259 14.4 1 1057 13145 700001   UPPER FRAME 0.886 48.9 2 33782 192413 700002   LOWER FRAME 0.969 54.1 2 37949 170403 700003   LATERAL FRAME 0.792 43.2 2 16899 176751 700004   LATERAL FRAME 0.730 37.8 2 27077 88721 700005   CENTRAL LEAF 0.728 38.4 2 31850 81824 700006   WHEEL LEAF 0.637 33.8 2 18271 75642 700007   PLINTH 1.094 55.1 2 30095 352956 700008   FIXED FRAME – WITHOUT CLIP 0.732 40.4 3 23585 142060 700009   FIXED FRAME – WITH CLIP 0.617 31.4 3 13304 98846 700010   OVERLAP 0.194 12.2 1 268 15205 700011   OVERLAP ANGLE 35 MM 0.408 24 1 12142 95110 700031   LATERAL FRAME WITH 140 MM GUIDE 1.418 76.6 1 138054 1389668 700032   LATERAL FRAME WITH 140 MM GUIDE 1.418 76.6 1 137063 1467325 700033   LATERAL FRAME WITH 120 MM GUIDE 1.306 70.9 1 115511 913694 700034   LATERAL FRAME WITH 120 MM GUIDE 1.306 70.9 1 114535 971478 700040   SIDE LEAF – DOUBLE GLASS 0.662 35.5 2 25154 70738 700041   4-LEAVES PROFILE 0.324 18.7 1 3943 7475 700050   CENTRAL LEAF – DOUBLE GLASS 0.699 37 2 30883 74138 700060   WHEEL LEAF – DOUBLE GLASS 0.614 33 2 17617 66992 700061   SINGLE GLASS SEPARATOR 0.511 28.1 2 14106 37590 700062   DOUBLE GLASS SEPARATOR 0.454 26.1 2 12762 25612 700063   MULLION – 21 MM GLASS GAP 0.554 30.1 2 18075 29478 700070   PLINTH – DOUBLE GLASS 1.020 53.4 2 28437 293319 700083   FIXED FRAME – 3 RAILS 1321 63.6 3 50098 443865 700100   WINDOW JUNCTION 0.502 25.1 2 3642 154241 700101   OVERLAP 33 MM 0.199 11.7 1 626 11977 700102   OVERLAP 43 MM 0.234 13.7 1 721 22263 700103   OVERLAP 60 MM 0.331 17.3 1 977 54828 700104   OVERLAP 87 MM 0.441 22.8 1 1133 141429 700105   OVERLAP ANGLE 60 MM 0.496 29 1 35669 142114 700106   OVERLAP ANGLE 40 MM 0.426 25 1 16210 102127 700107   OVERLAP 33 MM 0.197 10.6 1 450 9895 700108   CURVED OVERLAP 0.428 21.4 1 3631 67310 700140   SIDE LEAF – GLASS GAP 21 MM 0.649 34.9 2 24696 66390 700141   4-LEAVES PROFILE 0.341 18.3 1 3889 8412 700150   CENTRAL LEAF – GLASS GAP 21 MM 0.700 37.1 2 31375 70675 700160   WHEEL LEAF – GLASS GAP 21 MM 0.631 33.4 2 19993 68859 700170   PLINTH – 21 MM GLASS GAP 1.082 55.1 2 31801 335754 700301   UPPER FRAME – 3 RAILS 1.540 74.7 2 66223 611216 700302   LOWER FRAME – 3 RAILS 1.676 81.3 2 73045 576723 700303   LATREAL FRAME – 3 RAILS 1.111 54.5 2 21691 506658 000234   SIDE LEAF 0.601 34.5 2 22035 55485 000236   WHEELED LEAF 0.536 30.8 2 15223 45111 000237   PLINTH 0.988 55.6 2 28306 323081 002340   SIDE LEAF – DOUBLE GLASS 0.571 32.9 2 21468 47912 002360   WHEELED LEAF – DOUBLE GLASS 0.501 29.5 2 14452 37604 002370   PLINTH – DOUBLE GLASS 0.949 54.2 2 27487 290427 23100   PRE-FRAME 50 MM – THICKNESS 1.1 MM 0.373 24.9 2 7997 33947 23705   CENTRAL LEAF 0.588 33.4 2 25641 46140 23750   CENTRAL LEAF – DOUBLE GLASS 0.558 31.7 2 24971 39742 72016

bienveneu dans salone musique de ali

18/08/2006 01:01 par aluminuom123

aluminuom

13/08/2006 02:25 par aluminuom123

aluminuom

13/08/2006 02:25 par aluminuom123

aluminuom

13/08/2006 02:24 par aluminuom123

aluminuom

13/08/2006 02:23 par aluminuom123

aluminuom

12/08/2006 01:40 par aluminuom123

aluminuom

12/08/2006 01:35 par aluminuom123
